T3 Turbocharger Oil-Cooled V-Band .63 A/R Universal Turbo For 1.5L–2.5L Engines

T3 Turbocharger Oil-Cooled V-Band .63 A/R Universal Turbo For 1.5L–2.5L Engines

Increase performance and boost potential with this universal T3 oil-cooled turbocharger. Designed for 1.5L–2.5L 4 and 6-cylinder engines, this turbocharger features durable construction, precision balancing, and high-quality materials to deliver reliable performance for street, performance, and custom turbo applications.

Important Notice:

• Pick-up service is not available

• This is a universal application turbocharger

• Modification may be required depending on vehicle setup

• Please check specifications carefully before purchasing

• Please ensure sufficient installation space is available

• Professional installation is strongly recommended

• No installation instructions are included

Vehicle Compatibility:

• Universal Application

Suitable for:

• 1.5L–2.5L 4 Cylinder Engines

• 1.5L–2.5L 6 Cylinder Engines

⚠ This turbocharger is not vehicle specific. Compatibility must be confirmed before purchase.

Package Includes:

• 1 × T3 Turbocharger

• Accessories as shown in product images

Product Information:

• Product Type: Universal T3 Turbocharger

• Condition: Brand New

• Cooling Type: Oil Cooled

• Bearing Type: Journal Bearing

• Wastegate: Internal Wastegate

• Thrust Bearing: 270 Degree

• Horsepower Capability: Up to 420HP

Specifications:

Turbocharger

• Turbo Flange: T3 4-Bolt

• Exhaust Outlet: V-Band

• Exhaust Outlet ID/OD: 2.5" / 3.1"

• Turbine A/R: 0.63

• Compressor A/R: 0.50

Turbine Wheel

• Inducer Diameter: 64.8mm

• Exducer Diameter: 55.8mm

• Trim: 74.2

• Exhaust Outlet: 79mm

• Exhaust Inlet: 44.7mm Length / 85.8mm Width

Compressor Wheel

• Inducer Diameter: 52.7mm

• Exducer Diameter: 76mm

• Trim: 48.1

• Compressor Inlet: 51.5mm

• Compressor Outlet: 78mm

Oil Connections

• Oil Inlet: M12 x 1.25 & 2 × M8 x 1.25

• Oil Outlet: 2 × M8 x 1.25

Materials

• Turbine Housing: Ductile Iron QT450-10

• Temperature Resistance: Up to 700°C

• Turbine Wheel: K418 Alloy

• Temperature Resistance: Up to 900°C

• Compressor Housing: ZL104 Aluminium

• Compressor Wheel: Cast Aluminium

Features & Benefits

• Universal T3 turbocharger design

• Oil-cooled for reliable operation

• Supports applications up to 420HP

• High-strength turbine housing and wheel construction

• Precision journal bearing design

• V-Band exhaust outlet

• 100% balancing tested

• Built for durability and long service life

Technology Features

• TURBOTECHNICS VSR3 Balancing Tested

• G3-Min-Flow VNT Turbo Testing

• Advanced Actuator Testing and Programming

Warranty:

• 2 Year Warranty

Shipping:

• Orders dispatched within 2 business days after cleared payment

• Orders placed after 9:30am AEDST may ship the next business day

• Tracking uploaded within 24 hours of dispatch

• Delivery timeframes may vary depending on location and carrier

Returns & Warranty:

• 30-day returns accepted in original unused condition

• Warranty covers manufacturing defects only

• Labour, installation, tuning, or consequential costs are not covered

• Buyer is responsible for return shipping unless item is faulty

Compatibility & Fitment Disclaimer:

• This turbocharger is a universal application product

• Modification and custom fabrication may be required

• Additional components may be required for installation

• Compatibility is provided as a guide only

• Buyer must confirm suitability before purchase

• Professional installation is strongly recommended

Installation Notice:

• Air filtration must be installed and maintained correctly

• Ensure oil supply and oil drain systems are correctly configured

• Oil drain line must sit lower than the turbocharger

• Inspect and rectify any issues that caused previous turbocharger failure

before installation:

• Additional supporting modifications may be required

• Seller is not responsible for damage caused by improper installation or tuning
